STA enclosures with Cam-Lok® quick connectors are versatile and safe.
Flush mount 200 amps model.
Low-voltage terminal block located in lower part of the box.
Door with key and padlock ring.
Mont-Tremblant Village, custom made multi-service enclosure with partition and individual door: 1 section 600 volts, 1 section 120/240 and 1 low voltage section.
VARIOUS APPLICATIONS OF STA BOXES:
- Generator
- Load bank
- Performance hall
- Permanent facility
- Equipment rental/leasing
- Indoor or outdoor uses
TECHNICAL SPECIFICATIONS
- Voltage available: 120/240, 208, 120/208, 347/600, 480, 600 – single or three phases
- Amperage available: 200, 400, 600, 800, 1000, 1200, 1600, 2000, 2400, 2800 and 3200
- Cam-Lok type: Series E-1016, 400 Amps, Cooper Crouse-Hinds, female or male model
- CU-AL mechanical lug included
- OPTIONAL:
- Fuse or unfused disconnect switches available on 200 and 400 amps models
- Available option of 20A, 30A or 50A power outlets rated for 120 or 120/240 volts
- Low-voltage terminal block option
ENCLOSURE SPECIFICATIONS
- Nema 1 indoor use, grey or black painted steel
- Nema 3R, textured ASA-61 grey painted steel
- Nema 3R (4X) in stainless steel #304
- Nema 3R (4X) in stainless steel #316
- Available in aluminium
- Door with 3 point lock, key and padlock ring
- Lockable gasketed trap door to prevent insects and bird nests
- Optional flush mount hardware available
FEATURES and BENEFITS
- Main feeder can enter through the sides, top or back of the box.
- Optional side section available for main feeder power coming from underground.
- All mechanical lug installed and ready to receive client’s wiring.
- Custom size and finish available on request.
- Custom made multi-service enclosure with partition and individual door.
